MN 305

5,5 kW - 50 Hz - 1 Phases

kW / HP : 5.5 / 5.5
rpm : 3000
Emission :

USER MANUAL
INSTALLATION INSTRUCTIONS
PRODUCT BROCHURE

Features
Engine
Dimensions
Alternator

Features

Model and Values	50 Hz Model	60 Hz Model
Continuous Power (kW/kVA)	5,5/5,5	6,8/6,8
Voltage (V)	230	240
Amps (A)	24	28,1
Phases	1	1
Hz	50	60
Engine Rpm	3000	3600
Noise Level (7m / 3m / 1m dB)	61 / 65 / 69

Technical specifications are subject to change without prior notice.
Dimensions and weight may vary depending on specific specifications.
Photos may show equipment that is not standard.

Engine

Engine Specifications
Base	KUBOTA
Type	Vertical, water cooled 4-cycle diesel engine
Cylinders	2
Bore X Stroke (Mm)	67,0 x 68,0
Displacement (L)	0.479
Compression Ratio	23,5
Combustion System	Indirect Injection
Aspiration	Natural Aspiration
Fuel Consumption On Load	2,3 L/h

Dimensions

Weight (KG)
Canop (Dry)	171
Standard Version (Dry)	139

Alternator

Alternator
Brand	NSM
Number of Poles	2
Insulation Type	H
IP Protection Class	23
Power Factor (Cos Phi)	1
Tropicalization	IT
Excitation System	Brushless
Voltage Regulation Accuracy	+5% (cosQ = 1)
