AB 197/130
LPG
Features
| Technical Specifications | |
|---|---|
| Base | Kubota |
| Type | Vertical, water cooled 4-cycle IDI diesel engine |
| Cylinders | 4 |
| Bore x stroke - mm(in) | 100,0 x 120,0 (3.937 x 4.724) |
| Aspiration | Turbocharged |
| Displacement - L (cu.in) | 3.769 (230,0) |
| Compression ratio | 19 |
| Power rating | 95.6 (130) / 3000 |
| Maximum torque - Nm (lb-ft) / rpm | 325.0 (239.7) / 1500 |
| Fuel injection pump type | In-line pump |
| Starter (V - kW) / alternator (V - W) | 12 - 3.0 / 12 - 1080 |
| Weight* - (kg) | 312 KG |
| ID Ø salt water hose - (mm) | 33.7 (1") |
| ID Ø diesel fuel inlet hose - (mm) | 8 |
| ID Ø diesel fuel return hose - (mm) | 6 |
| Length x width x height - (mm) | 1136 x 630 x 738 |
*Without gearbox.
Technical specifications are subject to change without prior notice.
Dimensions and weight may vary depending on specific specifications.
Photos may show equipment that is not standard.
